Part Number: 813AGC-1
Description: North American Fuse Fast Acting 1A
Specifications

(Specifications subject to change without notice)

Part Number: 813AGC-1
Current Rating: 1A
Voltage Rating: 250VAC
Temperature Rating: 70ºC
Fuse Type: Fast Acting
Fuse Size: ¼" x 1¼"
Breaking Capacity: 35A
General Material: Glass
Color: Clear
CE Marking: no
REMARKS:

Last Modification: 03/10/20 • 08:59:36 • netui           *Specifications subject to change without notice

Printer Friendly
Printable version of Specifications
