Part Number: 81400890
Description: Replacement Fuse for British Plug.
Specifications

(Specifications subject to change without notice)

Part Number: 81400890
Current Rating: 13A
Voltage Rating: 240VAC
Temperature Rating: 35ºC Max*
Fuse Type: BS 1362
Fuse Size: 25.4mm
Breaking Capacity: 6000A
General Material: See remarks
Color: Brown
CE Marking: no
REMARKS: Material: Ceramic tube-end caps:silver-plated copper. *Note: 35ºC Max. for full load with a derating of 0.5% for every degree higher than 35ºC.

Last Modification: 11/27/19 • 07:38:49 • netui           *Specifications subject to change without notice
