Part Number: 81413421
Description: International Fuse Quick Acting 1A
Specifications

(Specifications subject to change without notice)

Part Number: 81413421
Current Rating: 1A
Voltage Rating: 250VAC
Temperature Rating: -25ºC to 70ºC
Fuse Type: Quick Acting
Fuse Size: 5x20mm
Breaking Capacity: 1500A High breaking
General Material: Brass Ceramic
Color: White
CE Marking: yes
REMARKS:
